Master Series High Power Highbay Lighting 500W

Short Description:

1. Die Casted Housing , Thermal Conductivity 96W/(m*k)@25C

2. Copper Breather Valve , Balance Internal and External Humidity and Pressure

3. Double SPD , Integrated 4-10KV Surge Protection and External 10KV Lighting Protector

4. Die Casted U Bracket , Highest Corrosion Resistance with Anti-Wind Level 17

5. Anti-UV Lens, 94% Transmittance with Customized Logo Environment Requirement

6. Working Temperature ：-35~+50C

7. Storage Temperature ：-35~+50C

Send email to us

Product Detail

Product Tags

Introdction

> Space series high bay is a patent product designed by famous Germany designer.
> The heat sink is made of die-cast aluminum with powder coating.
> Good heat dispation, light weight, and good anti-corrosion.
> Lifespan can reach up to 100000Hrs, with lumen output remain 78.24%.

Technical Specification

- Input Voltage : 100-277VAC
- Driver Type : UL Approved Flicker-free
- Luminous Efficacy :130-170lm/w
- Colour Rendering Index : > 80Ra
- LED Type : LM80 SMD LED
- Operating : Temperature:-30°C up to 50°C

- Color Temperature : 3000K/4000K/5000K/5700K
- Material : Die-cast Aluminum body & Polycarbonate Diffuser/Toughened glass
- Ingress Protection : IP66
- Impact Rating : IK08
- Rated Life : 50,000 hours
- Warranty : 5 years

Installation instruction

Note：The installation base must be able to support 10 times weight of the products

Luminaire Photometric

Safety Instructions

Becareful
1. Please use the product in accordance to this instruction
2. Please do not replace components or modify lamps without authorization

Attention
1. For your safety, please cut off the supply before install the product
2. For the well function, please choose the voltage within the range specified on the product.
3. To avoid damage to the eyes, do not stare at a LED Light source long time.
4. Please follow the correct installation steps to install this Product, for your safety, please cut off the electricity before installation.
