Giant Series High Mast Led Stadium Light

Short Description:

Operation Instruction for LED high mast light
Thank you for your purchase! Before install the product, reference.please read this instruction carefully, and keep it for further.


Product Detail

Product Tags

Characteristics

1. Die Casted Housing , Thermal Conductivity 96W/(m*k)@25℃

2. Copper Breather Valve , Balance Internal and External Humidity and Pressure

3. Double SPD , Integrated 4-10KV Surge Protection and External 10KV Lighting Protector

4. Die Casted U Bracket , Highest Corrosion Resistance wit Anti-Wind Level 17

5. Anti-UV Lens, 94% Transmittance with Customized Logo

High Mast Led Flood Light4

Environment Requirement

Working Temperature:-35~+50℃

Storage Temperature:-35~+50℃

Storage Humidity:0%~90%

Working Humidity:0%~85%

Product Information

Category LED High Mast Light
Wattage 400W 480W 800w 960w
Light Efficacy Up to 140lm/W
Beam Angle 10°125°145°/60°/90°
Input Voltage AC100-277V
cCT 2700-6500K
CRI 70/ 8o
Working Temperature -35~+50℃
Lifespan 60000H
lGrade IP 66

Installation instruction

K5JOTS12R{5M8C23`3F9`0X

Safety Instructions

▷ Becareful
1.Please use the product in accordance to this instruction.
2.Please do not replace components or modify lamps withou tauthorization.

▷ Attention

1.For your safety, please cut off the supply before install theproduct
2.For the well function,please choose the voltage within therange specified on the product.
3.To avoid damage to the eyes, do not stare at a LED Lightsource long time.
4.Please follow the correct installation steps to install this product, for your safety,please cut off the electricity before installation.
